Flir E4 Infared Camera with MSX

$999.00

SKU: 26236 Categories: , , ,

The FLIR E4 thermal imaging camera is an easy-to-use troubleshooting tools for building, electrical, and mechanical applications. Find hidden problems, take accurate temperature readings, and confirm repairs were done correctly with the help of the 4,800 (80 x 60) pixel infrared resolution and FLIR Multi-Spectral Dynamic Imaging (MSX®) enhancements.

HERE’S THE SPECS:

Accuracy
±2°C (±3.6°F) or ±2% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) and object temperature above 0°C (32°F)
Detector Type
Uncooled microbolometer
Field of view (FOV)
45° x 34°
IR Resolution
80 × 60 pixels
List of Contents
•Infrared camera •Hard transport case •Battery (inside camera) •USB cable •Power supply/charger with EU, UK, US and Australian plugs •Printed documentation
Multi Spectral Dynamic Imaging (MSX)
IR image enhanced with visible camera detail
Object Temperature Range
–20°C to 250°C (–4°F to 482°F)
Packaging Size
385 x 165 x 315 mm (15.2 x 6.5 x 12.4 in.)
Thermal Sensitivity/NETD
<0.15°C (0.27°F) / <150 mK




Resolution Comparison

Affordable Resolution Choices

From the 4800-pixel thermal image clarity of the E4 to the E8’s incredible 320×240 detector with 76,800 pixels, new FLIR Ex-Series cameras offer a resolution to fit the target size, working distance, and detail required for your application as well as your budget.
Compare camera resolutions


The Power of One Button

A focus-free lens and simple button navigation to on-screen settings, imaging modes, measurement tools, and saved JPEGS make all four of these cameras amazingly easy to operate, even with just the press of a single gloved thumb.
Explore the FLIR E4


Removable Battery

Quick-release, tool-type Li-ion battery is easy to remove, recharge and snap back in. Charge in-camera or with the optional charging station to keep you up and running all day.


Fast Temperature Measurement Tools

The E4 on up feature an on-screen center spotmeter for measuring temperatures. The E5, E6, and E8 also give you an area box tool with an automatic hot or cold spot that hunts down temperature extremes. And the E6 and E8 provide a blue-below and red-above color alarm to quickly alert you to heat issues.


Multiple Imaging Modes

All Ex-Series cameras let you view thermal, visual, and MSX images and store them simultaneously for further analysis using FLIR Tools software. The E6 and E8 also offer Picture-in-Picture that inserts the thermal image over the visible photo as an extra documentation option.

Electrical Panel - Thermal

Thermal Only

Electrical Panel - MSX

Thermal with MSX

Electrical Panel - PIP

Picture-in-Picture


Additional E4 , E5, E6 & E8 Features:

Weight 14 lbs
